317L stainless steel plate advantage

1. 1. Good corrosion resistance: The main alloy elements of 317 stainless steel are chromium, nickel and molybdenum, which makes it have excellent corrosion resistance and is especially suitable for use in strong acid, strong alkali and high temperature environments.
2. 2. Excellent mechanical properties: 317 stainless steel has high tensile strength and yield strength, high elongation, high hardness and impact toughness, and can still maintain stable performance in high temperature environments.
3. 3. Easy to process and weld: 317 stainless steel can be processed and deformed through a variety of methods, such as cold processing, hot processing, deep drawing, etc. In addition, it can be connected by conventional welding methods, such as argon arc welding, resistance welding, laser welding, etc.
4. 4. High temperature strength: 317 stainless steel can still maintain high strength and stable performance in high temperature environments, which makes it widely used in high temperature fields.
5. 5. It should be noted that the performance of 317 stainless steel may be affected by factors such as material condition, manufacturing process, use environment, etc. Therefore, sufficient evaluation and testing are required in specific applications.

317L stainless steel plate chemical composition

Carbon	Silicon	Sulfur	Phosphorus	Chromium	Molybdenum	Manganese	Nickel	Nitrogen
0.030	0.75	0.030	0.045	18.0-20.0	3.0-4.0	2.00	11.0-15.0	0.10

317L stainless steel plate mechanical property

Yield Strengtd 0.2% Offset		Ultimate Tensile Strength		Elongation in 2 in.	Hardness
psi (min.)	(MPa)	psi (min.)	(MPa)	% (min.)	(max.)
30,000	205	75,000	515	40	95 Rockwell B

317L stainless steel plate specification

Grade	201/202/301/303/304/304L/316/316L/317L/321/309S/310S/401/409/410/420J1 /420J2/430/439/443/444/630/631/904L/2205/2507/2520 etc
Surface Finish	2B, BA, NO.1, NO.4, 8K, HL, Embossing, Satin, Mirror, ect
Standard	JIS/SUS/GB/DIN/ASTM/AISI/EN
Technique	Cold Rolled; Hot Rolled
Thickness	0.3-4mm cold rolled; 3-100mm hot rolled; Customized according to customer requirements
Width	1000mm, 1219mm, 1240mm, 1500mm, 1800mm, 2000mm
Length	2000mm, 2438mm, 2500mm, 3000mm, 6000mm or as required
Application	Interior/Exterior decoration; Architectur; Evevator; Kitchen; Ceiling; Cabinet; Advertising nameplate; Roof structure;Shipbuilding
Lead Time	Normally 7-15 working days after the receipt of 30% deposit, according to the quantity
Payment Terms	30% TT for deposit,70% TT /70% LC at sight balance before shipment
Price Terms	FOB, EXW, CIF, CFR
Packing	Standard Sea Worthy Package or according to customer's requirements
