AH36 marine steel advantage

1.

   Reducing panel thickness reduces the weight of the final structure.

2.

   The payload is larger during use. Fatigue resistance, impact resistance, wear resistance, corrosion resistance,

3.

   Save welding and fabrication costs. High strength, high toughness, weather resistance, acid resistance, welding and easy processing.

AH36 marine steel application

1. 1.Marine Structures：AH 36 plate is widely used in the marine industry due to its excellent strength properties. Marine structures, such as shipbuilding, offshore wind farms, and oil rigs, require materials that can withstand harsh oceanic conditions. AH, 36 steel plate provides corrosion resistance, crucial when exposed to seawater and reduces the risk of structural damage. The durability and toughness of AH 36 plates make it perfect for constructing marine vessels and offshore industry platforms.
2. 2.Transportation Equipment：The transportation industry also uses AH 36 plates to construct the hulls of high-speed ferry boats, tanker trucks, and railroad cars. This industry demands materials that offer a better strength-to-weight ratio, high durability, and easy fabrication. AH 36 plates meet these requirements while adding the benefit of enhancing fuel efficiency for transportation equipment.
3. 3.Structural：Another common application of AH 36 plates is in the construction industry. The strength and durability properties of this material make it ideal for structural applications, such as building bridges, tunnels, and steel-framed structures. AH 36 plates are also corrosion-resistant, making them dependable for structures subjected to extreme atmospheric conditions, like saltwater or acid rain.
4. 4.Machinery and Equipment：AH 36 plates are also used in the manufacturing of machinery and equipment. Heavy machinery in the mining and construction industry requires materials that can handle heavy loads while retaining the durability needed to withstand harsh working environments. AH 36 plates are reliable and have low maintenance features, making it a perfect fit for heavy machinery.
5. 5.Pressure Vessels：The heavy-duty construction and strength of AH 36 plates make them excellent for industrial pressure vessels, such as boilers and containers. AH 36 plate’s high strength-to-weight ratio is critical in their use as pressure vessels. This kind of steel plate reduces the weight of the vessel’s wall as it provides more strength than the other types of steel plates.

AH36 marine steel chemical composition

Grade	C %	Si %	Mn %	P %	S %	V %	AL %	Cr %
KR Grade AH36	0.18	0.1-0.5	0.90-1.6	0.035	0.035	0.05-0.10	0.015	0.2
	Cu %	Mo %	Nb %	Ni %	Ti %
	0.35	0.08	0.02-0.05	0.4	0.02

AH36 marine steel mechanical property

Grade	Thickness(mm)	MinYield(Mpa)	Tensile(Mpa)	Elongation (%)	Min Impact Energy
KR Grade AH36	8mm-50mm	Min 355Mpa	490-620Mpa	21%	-0	34J
	51mm-70mm	Min 355Mpa	490-620Mpa	21%	-0	41J
	71mm-100mm	Min 355Mpa	490-620Mpa	21%	-0	50J
The min impact energy is longitudinal energy

AH36 marine steel specification

Product name	AH36 marine steel specification
Standard	EN, DIN, ASTM, ASME, AISI, JIS, IS, AS, GB/T
Place of Origin	China
Steel grade	S235, S275, S355, S420, S460, S500, S550, S690, P265, P355, P460, 16Mo3 42CrMo4, 1.2311, 1.2312, P20, C45, (S)A36, A283, A285, A572, A514, A517, A516, A299, A537, A387, A542, A203, A302, A514, A553, A533, A709, SAE1045, SAE1050 SS400, S35C, S45C, S50C, SM400, SM490 IS2041, IS2002, IS2062 AS3678Gr250, AS3678Gr350,AH36 Q235, Q275, Q345, Q420, Q460, Q500, Q690, Q345R, 20#, 35#, 45#
Processing service	cutting, painting, shot blasting
Certificate	MTC 3.1/3.2
Thickness	8-700mm, or as your request
Length	3000-18000mm, or as your request
Width	1500-4020mm, or as your request
Loading port	Shanghai / Qingdao / Lianyungang / Tianjin / Other main port, China
Payment terms	30% T/T deposit in advance, 70% T/T balance before shipment
Delivery time	Cargo ready at port: 10 days after receipt of deposit
