Spring steel plate is a flat rectangular steel plate in a curved shape. The chassis is made of several stacked pieces and is used for springs. One end is mounted on a hanger with a pin, and the other end is connected to the girder using a lifting eye to enable the spring to expand and contract. It is suitable for some hard-core off-road vehicles and medium and large trucks without load-bearing bodies.
1. Simple structure, reliable operation, low cost and easy maintenance. It is both the elastic element of the suspension and the guide device of the suspension. One end of it is articulated with the frame, which can transmit various forces and moments and determine the beating trajectory of the wheel.2. It has certain friction and shock absorption effect. Killing three birds with one stone, it is widely used in non-independent suspensions.| C | Si | Mn | S | P | Cr | Ni | Cu |
| 0.62～0.70 | 0.17～0.37 | 0.90～1.20 | ≤0.035 | ≤0.035 | ≤0.25 | ≤0.30 | ≤0.25 |
serial number | Trademark | Mechanical Property | |
tensile strength ób/MPa≤ | Elongation δ10(%)≥ | ||
1 | 85 | 800 | 10 |
2 | 65Mn | 850 | 12 |
3 | 55SiMn | 950 | 12 |
4 | 60SiMn | 950 | 12 |
5 | 60Si2MnA | 950 | 13 |
6 | 60Si2CrA | 1100 | 12 |
7 | 50CrVA | 950 | 12 |
Product Name: | Spring steel plate |
Thickness: | 0.6-300mm or as your request |
Normal Width: | 1250mm 1500mm 1800mm 2000mm etc. |
Length: | Customers' Requirement |
Technique: | Hot Rolled / Cold Rolled |
Suface Treatment: | Black Painted / Oiled /Galvanized |
Usage: | Widely used inmechanical manufacture,construction field,farm vehicles,agriculture greenhouse,automotive |
MOQ: | 1 Ton |
Supply Ability: | 20000 Tons / Month |
Payment Terms: | T/T , L/C，according to customers requirement |
