The iron plate for stair treads refers to an iron plate laid on the stair treads, mainly made of steel plates, cast iron plates, cold-drawn steel plates and other materials. Iron treads are more durable and wear-resistant than ordinary wood or ceramic tiles. They are also anti-slip, fireproof, and anti-corrosive, so they are widely used in industrial, commercial, and civil buildings.

email enquire now

Product Details

Tread plate Advantage

1. Long life: Iron pedals are more durable and less prone to wear and tear than wood or ceramic tiles, and their service life can reach decades.
2. Anti-slip and fire-proof: The surface of iron pedals is mostly designed with a flat grid or pebbled bottom, which has good anti-skid properties. At the same time, the materials used in iron pedals also have relatively good fire-proof properties.
3. High safety: Steel pedals are machine-made and have a stable production process, which guarantees certain safety. There will be no defects, cracks, wrinkles, etc. caused by poor production processes or material problems.
4. Anti-corrosion: The surface of iron pedals can also be treated with anti-corrosion, which can resist corrosion, oxidation and other damage and increase its service life.

Tread plate chemical composition

Grade	C	Mn	Si	P	S	N	Cu
EN10025-2 S235J0	0.17	1.4	-	0.03	0.03	0.012	0.55
EN10025-2 S235J2	0.17	1.4	-	0.025	0.025	-	0.55
EN10025-2 S235JR	0.17	1.4	-	0.035	0.035	0.012	0.55
EN10025-2 S275J0	0.18	1.5	-	0.03	0.03	0.012	0.55
EN10025-2 S275J2	0.18	1.5	-	0.025	0.025	0.012	0.55
EN10025-2 S275JR	0.21	1.5	-	0.035	0.035	0.012	0.55
EN10025-2 S355J0	0.2	1.6	0.55	0.03	0.03	0.012	0.55
EN10025-2 S355J2	0.2	1.6	0.55	0.025	0.025	-	0.55
EN10025-2 S355JR	0.24	1.6	0.55	0.035	0.035	0.012	0.55
EN10025-2 S355K2	0.2	1.6	0.55	0.025	0.025	-	0.55
EN10025-2 S420J0	0.2	1.7	0.55	0.03	0.03	0.025	0.55

Tread plate mechanical property

Grade	Yield Strength (MPa)	Ultimate Tensile Strength (MPa)	Elongation at Break (%)
EN10025-2 S235J0	235	360-510	17
EN10025-2 S235J2	235	360-510	15
EN10025-2 S235JR	235	360-510	17
EN10025-2 S275J0	275	410-580	15
EN10025-2 S275J2	275	410-580	13
EN10025-2 S275JR	275	410-580	15
EN10025-2 S355J0	355	470-680	14
EN10025-2 S355J2	355	470-680	14
EN10025-2 S355JR	355	470-680	14
EN10025-2 S355K2	355	470-680	12
EN10025-2 S420J0	450	550-720	17

Tread plate Specification

Production Standard	ASTM, B209, JIS H4000-2006,GB/T2040-2012,etc
Material	1000 2000 3000 4000 5000 6000 7000 8000
Width	50mm-2500mm or as the customer’s request
Longth	or as the customer’s request
Thickness	0.12mm-260mm
Surface	Coated, Embossed,Brushed, polished, Anodized,etc
OEM service	Perforated, Cutting special size, Doing flatness, Surface treatment,etc
Payterm	Ex-work, FOB, CIF , CFR, etc
Payment	T/T, L/C, Western Union, etc
Delivery Time	Within 3 days for our stock size,15-20days for our production
Package	Export standard package: bundled wooden box, suit for all kinds of transport, or be required
MOQ	200kg
Sample	Free and available
Quality	Certificate of Test,JB/T9001C,ISO9001,SGS,TVE
Export To	Ireland,Singapore,Indonesia,Ukraine,SaudiArabia,Spain,Canada,USA,Brazil,Thailand,Korea, India,Egypt,Kuwait,Oman,Viet Nam,South Africa,Dubai,England,Holland,Russia,etc
Application	Construction filed, Ships building industry, Decoration, Industry,Manufacture,Machinery and hardware fields, etc
