Hydraulic seamless tubes are typically made of several alloys and solid round steel bars of metals such as stainless steel, carbon steel, tungsten, etc. These metal pieces are converted into hollow tubes by heating and rolling over to the required forms.Seamless tubes are considered to be strong enough to resist high pressure from numerous industrial forces.

email enquire now

Product Details

seamless hydraulic tube Chemical Composition

Grade	C	Mn	Si	P	S	Nb	V	Al	Ti	Cr	Mo	N	Ni
EN10025-3 S275N	0.2	0.45-1.60	0.45	0.035	0.03	0.06	0.07	0.015	0.06	0.35	0.13	0.017	-
EN10025-3 S275NL	0.2	0.45-1.60	0.45	0.03	0.035	0.06	0.07	0.015	0.06	0.35	0.13	0.017	-
EN10025-3 S355N	0.2	0.85-1.75	0.55	0.035	0.03	0.06	0.14	0.015	0.06	0.35	0.13	0.017	0.55
EN10025-3 S355NL	0.2	0.95-1.75	0.55	0.03	0.025	0.06	0.14	0.015	0.06	0.35	0.13	0.017	0.85
EN10025-3 S420N	0.2	0.95-1.80	0.65	0.035	0.03	0.06	0.22	0.015	0.06	0.35	0.13	0.027	0.85
EN10025-3 S420NL	0.22	0.95-1.80	0.65	0.03	0.025	0.06	0.22	0.015	0.06	0.35	0.13	0.027	0.85
EN10025-3 S460N	0.22	0.95-1.80	0.55	0.035	0.03	0.06	0.22	0.015	0.06	0.35	0.13	0.027	0.85
EN10025-3 S460NL	0.22	0.95-1.80	0.65	0.03	0.025	0.06	0.22	0.015	0.06	0.35	0.13	0.027	0.85

seamless hydraulic tube Mechanical Property

Grade	Yield Strength (MPa)	Ultimate Tensile Strength (MPa)	Elongation at Break (%)
EN10025-3 S275N	275	370-510	23
EN10025-3 S275NL	275	370-510	23
EN10025-3 S355N	355	470-630	21
EN10025-3 S355NL	355	470-630	21
EN10025-3 S420N	420	520-680	18
EN10025-3 S420NL	420	520-680	18
EN10025-3 S460N	460	540-720	17
EN10025-3 S460NL	460	540-720	17

seamless hydraulic tube Specification

Type		seamless hydraulic tube
Materials		API 5L /A53 /A106 GRADE B and other material which client inquired
^Size	Outer Diameter	Seamless:17-914mm 3/8"-36"
	Wall Thickness	SCH10 SCH20 SCH30 STD SCH40 SCH60 XS SCH80 SCH100 SCH120 SCH140 SCH160 XXS
	Length	Single random length/Double random length 5m-14m,5.8m,6m,10m-12m,12m or as customer's actual request
Ends		Plain end/Beveled,protected by plastic caps on both ends, cut quare,grooved,threaded and coupling,etc.
Surface Treatment		Bare,Painting black,varnished,galvanized,anti-corrosion 3PE PP/EP/FBE coating
Technical Methods		Hot-rolled/Cold-drawn/Hot-expanded
Testing Methods		Pressure test,Flaw detection,Eddy current testing, Hydro static testing or Ultrasonic examination and also with chemical and physical property inspection
Packaging		Small pipes in bundles with strong steel strips,large pieces in loose; Covered with plastic woven bags; Wooden cases; Suitable for lifting operation; Loaded in 20ft 40ft or 45ft container or in bulk; Also according to customer's requests
Origin		China
Application		Conveying oil gas and water
Third Party Inspection		SGS BV MTC
Trade Terms		FOB CIF CFR
Payment Terms		FOB 30%T/T, 70% before shipment CIF 30% pre-payment and the balance to be paid before making shipment or Irrevocable 100% L/C at sight
MOQ		10 tons
Supply Capacity		5000 T/M
Delivery Time		Usually within 10-45 days after receipt of advance payment
