431 stainless steel pipe--S43100 (American AISI, ASTM), the corresponding Chinese grade of 431 is 1Cr17Ni2. Chinese name 431 stainless steel pipe Chinese brand 1Cr17Ni2 Characteristics: High strength resistance to nitric acid and organic acid corrosion Characteristics and uses: Parts with high strength resistance to nitric acid and organic acid corrosion.
1. High strength: AISI431 stainless steel has excellent strength and hardness, allowing it to withstand high stress and load.2. Corrosion resistance: This stainless steel performs well in acidic, alkaline and salt water environments and has excellent corrosion resistance.3. Magnetism: AISI431 stainless steel has certain magnetism and can be used in magnetic applications.| JIS | AISI | C | Si | Mn | P | S | Ni | Cr | Mo | Cu | N | |
| SUS431 | 431 | Max.0.20 | Max.1.00 | Max.1.00 | Max.0.040 | Max.0.030 | 1.25~2.50 | 15.00~17.00 | - | - | - | - |
| Standard | GB,AISI,ASTM,DIN,EN,JIS |
| Grade | Stainless steel 304 / 304L / 310S / 316L / 316Ti / 316LN / 317L / 431/904L / 2205 / 2507 / 32760 / 253MA / 254SMo / XM-19 / S31803 / S32750 / S32205 / F50 / F60 / F55 / F60 / F61 / F65 etc |
| Monel 400 / Monel K-500 | |
| Inconel 600 / Inconel 601 / Inconel 625 / Inconel 617 / Inconel 690 / Inconel 718 / Inconel X-750 | |
| Incoloy A-286 / Incoloy 800 / Incoloy 800H / Incoloy 800HT | |
| Incoloy 825 / Incoloy 901 / Incoloy 925 / Incoloy 926 | |
| Nimonic 75 / Nimonic 80A / Nimonic 90 / Nimonic 105 / Nimonic C263 / L-605 | |
| Hastelloy B / Hastelloy B-2 / Hastelloy B-3 / Hastelloy C / Hastelloy C-276 / Hastelloy C-22 | |
| Hastelloy C-4 / Hastelloy C-2000 / Hastelloy G-35 / Hastelloy X / Hastelloy N | |
| PH stainless steel 15-5PH / 17-4PH / 17-7PH | |
| Inspection | TUV,SGS,BV,ABS,LR and so on |
| Application | Chemical, Pharmaceutical & Bio-Medical, Petrochemical & Refinery, Environmental, Food Processing, Aviation, Chemical Fertilizer, Sewage Disposal, Desalination, Waste Incineration etc. |
| Processing Service | Machining : Turning / Milling / Planing / Drilling / Boring / Grinding / Gear Cutting / CNC Machining |
| Deformation processing : Bending / Cutting / Rolling / Stamping | |
| Welded | |
| Forged | |
| Sample | Free |
| Tempering Temperature (°C) | Tensile Strength (MPa) | Yield Strength 0.2% Proof (MPa) | Elongation (% in 50mm) | Hardness Brinell (HB) | Impact Charpy V (J) |
| Annealed * | 862 | 655 | 20 | 285 max | – |
| 204 | 1345 | 1055 | 20 | 388 | 50 |
| 316 | 1295 | 1035 | 19 | 375 | 53 |
| 427 | 1350 | 1080 | 19 | 388 | # |
| 538 | 1140 | 965 | 19 | 321 | # |
| 593 | 1015 | 770 | 20 | 293 | 64 |
| 650 | 960 | 695 | 20 | 277 | 84 |
