317L stainless steel pipe is a brand of stainless steel produced in accordance with American ASTM standards. Belonging to heat-resistant steel, 317L is equivalent to my country's 00Cr19Ni13Mo3 stainless steel pipe. 317 contains 18.0-20.0% chromium, 11.0-15.0% nickel, and 3.0-4.0% molybdenum.
1. Excellent corrosion resistance: 317L stainless steel has excellent corrosion resistance in corrosive media such as strong acid, strong alkali, sea water, chloride, etc., and is an ideal corrosion-resistant material. The material also has excellent high temperature resistance and can still maintain stable corrosion resistance at high temperatures.2. High strength and stability under high temperature: 317L stainless steel has high strength and hardness, and can still maintain stable performance in high temperature environments. Therefore, it is often used in machinery manufacturing and processing under high temperature conditions.3. Easy processability and weldability: 317L stainless steel has good processability and weldability, and is easy to perform molding, welding, cutting and other processing operations, making it convenient for material manufacturing and processing.4. Excellent anti-oxidation performance: 317L stainless steel has high anti-oxidation performance and can maintain good stability under high-temperature oxidation conditions, making it perform well in high-temperature working environments.| Carbon | Silicon | Sulfur | Phosphorus | Chromium | Molybdenum | Manganese | Nickel | Nitrogen |
| 0.030 | 0.75 | 0.030 | 0.045 | 18.0-20.0 | 3.0-4.0 | 2.00 | 11.0-15.0 | 0.10 |
| Yield Strengtd 0.2% Offset | Ultimate Tensile Strength | Elongation in 2 in. | Hardness | ||
| psi (min.) | (MPa) | psi (min.) | (MPa) | % (min.) | (max.) |
| 30,000 | 205 | 75,000 | 515 | 40 | 95 Rockwell B |
Item | Stainless Steel Pipe/Tube | |
Standard | ASTM A213,A312,ASTM A269,ASTM A778,ASTM A789,DIN 17456, DIN17457,DIN 17459,JIS G3459,JIS G3463,GOST9941,EN10216, BS3605, | |
Material | 304,304L,309S,310S,316,316Ti,317,317L,321,347,347H,304N,316L, 316N,201,202 | |
Surface | Polishing,annealing,pickling,bright | |
Type | hot rolled and cold rolled | |
Stainless steel round pipe/tube | ||
Size | Wall thickness | 1mm-150mm(SCH10-XXS) |
Outer diameter | 1mm-150mm(SCH10-XXS) | |
stainless steel square pipe/tube | ||
Size | Wall thickness | 1mm-150mm(SCH10-XXS) |
Outer diameter | 4mm*4mm-800mm*800mm | |
stainless steel rectangular pipe/tube | ||
Size | Wall thickness | 1mm-150mm(SCH10-XXS) |
Outer diameter | 1mm-150mm(SCH10-XXS) | |
Length | 4000mm,5800mm,6000mm,12000mm,or as required. | |
Element | 201 | 202 | 304 | 316 | S31803 | S32750 | |
C | ≤0.15 | ≤0.15 | ≤0.08 | ≤0.08 | ≤0.030 | ≤0.030 | |
Si | ≤1.00 | ≤1.00 | ≤1.00 | ≤1.00 | ≤1.00 | ≤0.80 | |
Mn | 5.5-7.5 | 7.5-10.0 | ≤2.00 | ≤2.00 | ≤2.00 | ≤1.20 | |
P | ≤0.060 | ≤0.060 | ≤0.045 | ≤0.045 | ≤0.030 | ≤0.035 | |
S | ≤0.030 | ≤0.030 | ≤0.030 | ≤0.030 | ≤0.020 | ≤0.020 | |
Cr | 16-18 | 17-19 | 18-20 | 16-18 | 21-23 | 21-23 | |
Ni | 3.5-5.5 | 4.0-6.0 | 42958 | 43022 | 4.5-6.5 | 6.0-8.0 | |
Mo | 2.0-3.0 | 2.5-3.5 | 3.0-5.0 | ||||
N | ≤0.25 | ≤0.25 | 0.08-0.2 | 0.24-0.32 | |||
Cu | ≤0.50 |
