Alloy Steel Pipe is used in applications which require moderate corrosion resistance properties with good durability and at an economical cost. There are two classes of alloy steels - high alloys and low alloy steels. Pipes that constitute low alloy steels have an alloying content that ranges below 5%. Whereas the alloying content of a high alloy steel would range between 5% to about 50%.
Its performance is much higher than ordinary seamless steel pipes. Alloy pipes are divided into structural seamless pipes and high-pressure heat-resistant alloy pipes. Mainly different from alloy pipes and their industry production standards, the annealing and tempering of alloy pipes changes their mechanical properties. meet the required processing conditions. Its performance is higher than ordinary seamless steel pipe. The chemical composition of alloy pipes contains more Cr and has the characteristics of high temperature resistance, low temperature resistance and corrosion resistance.
| Specifications | ASTM A 335 ASME SA 335 |
| Dimensions | ASTM, ASME and API |
| Size | 1/8″NB TO 30″NB IN |
| Tubing Size | 1 / 2” OD up to 5” OD, customs diameters also available |
| Outer Diameter | 6-2500mm; WT:1-200mm |
| Schedule | SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS |
| Grade | STM A335 Gr. P5, P9, P11, P12, P21, P22 & P91, ASTM A213 – T5, T9, T11, T12, T22, T91, ASTM A691 |
| Length | Within 13500mm |
| Type | Seamless / Fabricated |
| Form | Round, Hydraulic Etc |
| Length | Single Random, Double Random & Cut Length. |
| End | Plain End, Beveled End, Treaded |
| Grade | Chemical Composition% | ||||||||
| C | Si | Mn | P, S Max | Cr | Mo | Ni Max | V | Al Max | |
| T11 | 0.05~0.15 | 0.50~1.00 | 0.30~0.60 | 0.025 | 1.00~1.50 | 0.44~0.65 | – | – | – |
| T12 | 0.05~0.15 | Max 0.5 | 0.30~0.61 | 0.025 | 0.80~1.25 | 0.44~0.65 | – | – | – |
| T22 | 0.05~0.15 | Max 0.5 | 0.30~0.60 | 0.025 | 1.90~2.60 | 0.87~1.13 | – | – | – |
| T91 | 0.07~0.14 | 0.20~0.50 | 0.30~0.60 | 0.02 | 8.0~9.5 | 0.85~1.05 | 0.4 | 0.18~0.25 | 0.015 |
| Grade | Chemical Composition% | Mechanical Properties | |||||||
| W | B | Nb | N | T. S | Y. P | Elongation | Hardness | ||
| T11 | – | – | – | – | ≥ 415MPa | ≥ 205MPa | ≥ 30% | 163HBW(85HRB) | |
| T12 | – | – | – | – | ≥ 415MPa | ≥ 220MPa | ≥ 30% | 163HBW(85HRB) | |
| T22 | – | – | – | – | ≥ 415MPa | ≥ 205MPa | ≥ 30% | 163HBW(85HRB) | |
| T91 | – | – | 0.06~0.10 | 0.03~0.07 | ≥ 585MPa | ≥ 415MPa | ≥ 20% | 250HBW(25HRB) | |
