Low carbon steel plates are a type of material that is widely used. They are divided into ordinary low carbon steel plates and special steel plates, including low alloy high-strength steel and corrosion-resistant and heat-resistant clad steel plates. Ordinary low-carbon steel plates are divided into two types: cold-rolled and hot-rolled. Cold-rolled steel plates have good surface quality and precise thickness dimensions, and are mostly used to manufacture car bodies and the like. Hot-rolled plates are mostly used to make vehicle frames and the like.
1. Good plasticity: Compared with high carbon steel, low carbon steel has better plasticity and can be formed more easily. This is due to the low carbon content in low carbon steel, which reduces the brittleness and hardness of the steel, which is very helpful for processing and forming.2. High toughness: Low carbon steel is more tough than high carbon steel and can better withstand external impact and extrusion. This also makes mild steel ideal for the production of components for applications such as automotive and machinery.3. Good weldability: Low carbon steel with low carbon content has good weldability and can obtain good welding effects, which is beneficial to splicing and repair work in production.| Grade | C | Mn | Si | P | S | N | Cu |
| EN10025-2 S235J0 | 0.17 | 1.4 | - | 0.03 | 0.03 | 0.012 | 0.55 |
| EN10025-2 S235J2 | 0.17 | 1.4 | - | 0.025 | 0.025 | - | 0.55 |
| EN10025-2 S235JR | 0.17 | 1.4 | - | 0.035 | 0.035 | 0.012 | 0.55 |
| EN10025-2 S275J0 | 0.18 | 1.5 | - | 0.03 | 0.03 | 0.012 | 0.55 |
| EN10025-2 S275J2 | 0.18 | 1.5 | - | 0.025 | 0.025 | 0.012 | 0.55 |
| EN10025-2 S275JR | 0.21 | 1.5 | - | 0.035 | 0.035 | 0.012 | 0.55 |
| EN10025-2 S355J0 | 0.2 | 1.6 | 0.55 | 0.03 | 0.03 | 0.012 | 0.55 |
| EN10025-2 S355J2 | 0.2 | 1.6 | 0.55 | 0.025 | 0.025 | - | 0.55 |
| EN10025-2 S355JR | 0.24 | 1.6 | 0.55 | 0.035 | 0.035 | 0.012 | 0.55 |
| EN10025-2 S355K2 | 0.2 | 1.6 | 0.55 | 0.025 | 0.025 | - | 0.55 |
| Grade | Yield Strength (MPa) | Ultimate Tensile Strength (MPa) | Elongation at Break (%) |
| EN10025-2 S235J0 | 235 | 360-510 | 17 |
| EN10025-2 S235J2 | 235 | 360-510 | 15 |
| EN10025-2 S235JR | 235 | 360-510 | 17 |
| EN10025-2 S275J0 | 275 | 410-580 | 15 |
| EN10025-2 S275J2 | 275 | 410-580 | 13 |
| EN10025-2 S275JR | 275 | 410-580 | 15 |
| EN10025-2 S355J0 | 355 | 470-680 | 14 |
| EN10025-2 S355J2 | 355 | 470-680 | 14 |
| EN10025-2 S355JR | 355 | 470-680 | 14 |
| EN10025-2 S355K2 | 355 | 470-680 | 12 |
Material: | Q235,Q255,Q275,SS400,A36,SM400A,St37-2,SA283Gr,S235JR,S235J0,S235J2 |
Thickness: | 0.2-500mm,etc |
Width : | 1000-4000mm,etc |
Length: | 2000mm, 2438mm, 3000mm, 3500,6000mm,12000mm,or rolled,etc etc |
Standard: | ASTM,AISI,JIS,GB, DIN,EN |
Surface: | Black painted,PE coated,Galvanized,color coated, |
anti rust varnished,anti rust oiled,checkered,etc | |
Technique: | Cold Rolled, Hot Rolled |
Certification: | ISO, SGS,BV |
price terms: | FOB,CRF,CIF,EXW all acceptable |
Delivery Detail: | inventory About 5-7; custom-made 25-30 |
Loading port: | any port in China |
Packing: | standard export packing (inside:water proof paper,outside:steel covered with strips and pallets) |
Payment Terms: | T/T, L/C at sight,West Union,D/P,D/A,Paypal |
Container size: | 20ft GP:5898mm(Length)x2352mm(Width)x2393mm(High) |
40ft GP:12032mm(Length)x2352mm(Width)x2393mm(High) | |
40ft HC:12032mm(Length)x2352mm(Width)x2698mm(High) | |
Delivery Time | 14 Days |
