Hastelloy Tube Advantage

1. 1. Extremely high corrosion resistance: Hastelloy pipe material contains alloy elements such as chromium and molybdenum, which has extremely high corrosion resistance and can even prevent corrosion by chemical substances such as chloride ions. This is also one of the reasons why Hastelloy pipes are widely used in petroleum, chemical industry and other fields.
2. 2. High pressure resistance, safe and reliable: The unique material structure of Hastelloy alloy tube makes it have high strength and toughness. Even in high temperature and high pressure environment, the nickel-based alloy can maintain its stable performance and is not easy to deform and break. It has good shock resistance and vibration resistance.
3. 3. Good processability and plasticity: Hastelloy pipe has a smooth surface and no burrs and other defects on the inner wall. It is easy to process and install. It can also be processed by cold bending, flaring, shrinking, etc., which can meet the needs of different occasions.

Hastelloy Tube chemical composition

Hastelloy C276	Ni	C	Mo	Mn	Si	Fe	P	S	Co	Cr
	Balance	0.010 max	15.00 – 17.00	1.00 max	0.08 max	4.00 – 7.00	0.04 max	0.03 max	2.5 max	14.50 – 16.50

Hastelloy Tube mechanical property

STANDARD	WERKSTOFF NR.	UNS	JIS	BS	GOST	EN	OR
Hastelloy C276	2.4819	N10276	NW 0276	-	ХН65МВУ	NiMo16Cr15W	ЭП760

Hastelloy Tube specification

Prdouct Name	Hastelloy Tube
Grade	Hastelloy: Hastelloy B / B-2/B-3/C22/C-4/S/ C276/C-2000/G-35/G-30/X/N; Inconel: Inconel 100/600/601/602CA/617/625713/718738/X-750,Carpenter 20; Incoloy: Incoloy 800/800H/800HT/825/925/926; Monel: Monel 400/K500 Nimonic: Nimonic 75/80A/90 ;
Thickness	0.1-200 mm
Diameter	10-500 mm
Length	1-12 m
Application	Auto, turbines, blades, powder and engines，etc
Feature	High corrosion resistance, low density, good thermal stability
Surface	Bright, Polished, Pickling, Acid cleaning, Sandblasting
Quality and test	Hardness test, Bending test, Hydrostatic etc.
Surface	Polished
