Monel alloy K500 advantage

1. 1. Corrosion resistance: Monelk-500 alloy has excellent corrosion resistance and performs well against seawater, steam, acid, alkali and other media. Under harsh environmental conditions, Monelk-500 alloy can still maintain its stable performance and extend the service life of equipment.
2. 2. Low magnetic properties: Monelk-500 alloy has low magnetic permeability, giving it an advantage in magnetically sensitive applications. For example, in precision measuring instruments, aerospace and electronic equipment, Monelk-500 alloy can reduce magnetic field interference and maintain the accuracy and stability of the equipment.
3. 3. High strength: Monelk-500 alloy has excellent high strength, making it widely used in applications requiring tensile strength and impact resistance. It can be used to manufacture high-strength structural parts and equipment that can withstand high pressures.

Monel alloy K500 chemical composition

Monel k500	Ni	Fe	Mn	Si	Cu	Al	Ti
	63.0 min	<2	0.3 max	< 0.5	27-33	2.3-3.15	0.35/0.85

Monel alloy K500 mechanical property

related character	Tensile strength (MPa)	Yield strength (MPa)	ductility（%）	hardness （HB）
Corresponding figures	935/1275	655/1103	10/20	255/370

Monel alloy K500 specification

Material	Monel/Inconel/Hastelloy/Duplex Steel/PH Steel/Nickel Alloy
Shape	Round bar ,Coil,Square,Pipe,Sheet
Grade	Duplex: 2205(UNS S31803/S32205),2507(UNS S32750),UNS S32760(Zeron 100),2304,904L
	Others:253Ma,254SMo,654SMo,F50(UNSS32100)F60,F61,F65,1J22,N4,N6 etc
	Alloy : Alloy 20/28/31
	Hastelloy:HastelloyB/ -2/B-3/C22/C-4/S/ C276/C-2000/G-35/G-30/X/N/g
	Hastelloy B / UNS N10001,Hastelloy B-2 / UNS N10665 / DIN W. Nr. 2.4617,Hastelloy C, Hastelloy C-4 / UNS N06455 / DIN W. Nr. 2.4610,Hastelloy C-22 / UNS N06022 / DIN W. Nr. 2.4602, Hastelloy C-276 / UNS N10276 / DIN W. Nr. 2.4819,Hastelloy X / UNS N06002 / DIN W. Nr. 2.4665
	Haynes: Haynes 230/556/188
	Inconel 600/601/602CA/617/625/713/718/738/X-750,Carpenter 20
	Inconel 718 / UNS N07718 / DIN W. Nr. 2.4668,Inconel 601 / UNS N06601 / DIN W. Nr. 2.4851, Inconel 625 / UNS N06625 / DIN W. Nr. 2.4856,Inconel 725 / UNS N07725,Inconel X-750 / UNS N07750 / DIN W. Nr. 2.4669,Inconel 600 / UNS N06600 / DIN W. Nr. 2.4816
	Incoloy: Incoloy 800/800H/800HT/825/925/926;
	GH: GH2132,GH3030,GH3039,GH3128,GH4180,GH3044
	Monel: Monel 400/K500/R405
	Nitronic: Nitronic 40/50/60;
	Nimonic: Nimonic 75/80A/90/A263 ;
Specification	Wire: 0.01-10mm Strip: 0.05*5.0-5.0*250mm Bar: φ4-50mm;Length 2000-5000mm Pipe: φ6-273mm;δ1-30mm;Length 1000-8000mm Sheet: δ 0.8-36mm;Width 650-2000mm;Length 800-4500mm
Product  Characteristics	1.According to the preparation process can be divided into deformation superalloys, casting superalloys and powder metallurgy superalloys. 2.According to the strengthening mode, there are solid solution strengthening type, precipitation strengthening type, oxide dispersion strengthening type and fiber strengthening type, etc..
Application	High temperature components such as turbine blades, guide vanes, turbine disks, high pressure compressor disks,machine manufacturing and combustion chambers used in the manufacture of aviation, naval and industrial gas turbines
Packaging	1. cases packed in wooden cases 2. paper packaging 3. plastic packing 4. foam packaging Packaging according to customer requirements or products
Payment	L/C,T/T,Western Union,MoneyGram,According to customer requirements payments for offline orders.
