Monel 400 alloy is a kind of alloy with good corrosion resistance in seawater, chemical solvents, ammonia sulfur chloride, hydrogen chloride, various acidic media such as sulfuric acid, hydrofluoric acid, hydrochloric acid, phosphoric acid, organic acids, alkaline media, salts and molten salts. Performance nickel-based alloy material.
1. High corrosion resistance: Monel400 Monel alloy has excellent corrosion resistance and can be used for a long time in a variety of highly corrosive media, such as sulfuric acid, hydrofluoric acid, chloric acid, nitric acid, etc.2. Excellent stress corrosion resistance: Monel400 Monel alloy has excellent stress corrosion resistance and can be used for a long time in high stress and high temperature environments. For example, it is widely used in equipment manufacturing in marine environments.3. High strength and high wear resistance: Monel400 Monel alloy has high strength and high wear resistance, and can be used for a long time in a variety of harsh environments.4. Excellent oxidation resistance: Monel400 Monel alloy has excellent oxidation resistance and can be used for a long time in high temperature and high pressure environments.| Monel 400 | Ni | Fe | C | Mn | Si | Cu | Al | S |
| 63.0 min | 1.0 - 2.5 | 0.3 max | 2.0 max | 0.5 max | 28.0 - 34.0 | 0.50 max | 0.02 max |
| shape | strength of extension | yield strength (0.2% Offset) | tensile elongation % | hardness | |||
ksi | MPa | Brinell (3000-kg) | Rockwell B | ||||
bar | 70-110 | 480-760 | 25-85 | 170-585 | 50-5 | 110min | 60min |
sheet | 70-95 | 482-655 | 28-75 | 193-517 | 50-30 | 110-215 | 60-96 |
thin plate | 70-120 | 482-827 | 30-110 | 207-758 | 45-2 | 65min | |
belt | 70-140 | 482-965 | 25-130 | 172-896 | 50-2 | 68min | |
seamless tube | 70-130 | 482-896 | 25-110 | 172-758 | 50-3 | 100max | |
cold-drawn wire | 70-180 | 482-1241 | 30-170 | 207-1172 | 45-2 |
name | bright annealed solution Nickel Alloy Seamless Pipe | ||
type | round | ||
technique | cold drawn/hot rolled/forged | ||
other material | 200/300/400 series stainless steel, hastelloy/inconel/incoloy etc nickle alloy steel | ||
diameter | 1-1000mm | ||
length | as your request | ||
price term | EXW/FOB/CIF/CFR/FCA | ||
delivery term | TT/Western Union/LC | ||
packing | woven bag, or wooden case | ||
delivery time | 15-20 days | ||
