Honed tube is well known as hydraulic cylinder tube in many industries. This is because honed tubes are the most important materials of manufacturing hydraulic cylinders. And as this kind of tubing is usually honed in tube inside diameter, it is known as honed ID tubing also.

email enquire now

Product Details

honed tubing Advantage

a. High strength: Thick-walled spiral steel pipes have high tensile strength and yield strength, are suitable for withstanding large internal and external pressures, and provide solid support for various projects.
b. Good welding performance: High-quality steel and double-sided submerged arc welding process ensure high strength and high quality of welded joints.
c. Superior stress resistance: The spirally distributed welds help disperse and release stress, improving the stress resistance of the steel pipe.
d. High flexibility: The diameter and wall thickness of thick-walled spiral steel pipes can be easily adjusted during the production process to meet the needs of different application scenarios.
e. Strong corrosion resistance: High-quality steel and surface treatment technology can provide good corrosion resistance and ensure the service life of steel pipes in harsh environments.
f. Saving resources: Due to the high strength of thick-walled spiral steel pipes, thinner wall thicknesses can be used to achieve material savings on the premise of meeting engineering requirements.
Application fields: Thick-walled spiral steel pipes are widely used in various engineering fields, such as oil, natural gas, water conservancy, electric power, construction, bridges, etc. Its excellent performance characteristics make it an indispensable basic building material in various projects.

honed tubing Chemical Composition

Speci -cation	Grade	Chemical Composition [%]
		C		Mn		P	S	Si		Cr		Mo		Cu	Ni	V
		C		Mn		P	S	Si		Cr		Mo		Cu	Ni	V
		Min	Max.	Min	Max.	Max.	Max.	Min.	Max	Min.	Max	Min.	Max	Max	Max	Max
EN 10305-1/EN10305-4	E 235		0.17		1.2	0.025	0.025		0.35							0.02
EN 10305-1/EN10305-4	E 355		0.22		1.6	0.025	0.025		0.55							0.02
EN 10216-1	P195 TR1		0.13		0.7	0.025	0.02		0.35		0.3		0.08	0.3	0.3
EN 10216-1	P235 TR1		0.16		1.2	0.025	0.02		0.35		0.3		0.08	0.3	0.3
EN 10216-2	P235 GH		0.16		1.2	0.025	0.02		0.35		0.3		0.08	0.3	0.3	0.02
DIN 2391	St - 45	-	0.17	0.4	-	0.025	0.025	-	0.35	-	-	-	-	-	-	-
	St - 45	-	0.21	0.4	-	0.025	0.025	-	0.35	-	-	-	-	-	-	-
	St - 52	-	0.22	-	1.6	0.025	0.025	-	0.55	-	-	-	-	-	-	-
ASTM A-519	SAE 1010	0.08	0.13 0.20	0.3	0.6	0.04	0.05	-	-	-	-	-	-	-	-	-
	SAE 1018	0.15	0.28	0.6	0.9	0.04	0.05	-	-	-	-	-	-	-	-	-
	SAE 1026	0.22	0.38	0.6	0.9	0.04	0.05	-	-	-	-	-	-	-	-	-
	SAE 1035	0.32	0.44	0.6	0.9	0.04	0.05	-	-	-	-	-	-	-	-	-
	SAE 1040	0.37	0.21	0.6	0.9	0.04	0.05	-	-	-	-	-	-	-	-	-
	SAE 1518	0.15	0.44	1.1	1.4	0.04	0.05	-	-	-	-	-	-	-	-	-
	SAE 1541	0.36	0.33	1.35	1.65	0.04	0.05	-	-	-	-	-	-	-	-	-
	SAE 4130	0.28		0.4	0.6	0.04	0.04	0.15	0.35	0.8	1.1	0.15	0.25	-	-	-

honed tubing Mechanical Property

Speci -cation	Grade	Mechanical Properties
		Yield Strength		Tensile Strength			% Elongation (G.L. 50 mm WT 8 mm) e (min.)
		Min.		Min.
		PSI	MPa	PSI	MPa
EN 10305-1/EN10305-4	E 235		235		340	25
	E 355		355		490	22
EN 10216-1	P195 TR1		195		320	27
	P235 TR1		235		360	25
EN 10216-2	P235 GH
DIN 2391	St - 45	NBK : 215 / GBK : -		NBK : 340 / GBK : 315		NBK : 470
	St - 45	NBK : 255 / GBK : -		NBK : 440 / GBK : 390		NBK : 570
	St - 52	NBK : 355 / GBK : -		NBK : 490 / GBK : 490		NBK : 630
ASTM A-519	SAE 1010	As per Customer requirements
	SAE 1018
	SAE 1026
	SAE 1035
	SAE 1040
	SAE 1518
	SAE 1541
	SAE 4130

honed tubing Specification

Product Name	Honed tubing
Material	ST52, CK45, 4140, 16Mn, 42CrMo, E355, Q345B, Q345D, Stainless Steel 304/316, Duplex 2205,etc.
Delivery Condition	BK, BK+S, GBK, NBK
Straightness:	≤ 0.5/1000
Roughness:	0.2-0.4 u
Diameter	6mm - 1000mm
Length	1000mm - 12000mm
Tolerance EXT:	DIN2391, EN10305, GB/T 1619
Tolerance INT:	H7, H8, H9
Shape	Round
Technology	perforation /acid pickling / phosphorization /cold drawn /cold rolled /annealing/ anaerobic annealing
Protection:	anti-rust oil on inside and outside surface, plastic caps in both ends.
Used	Hydraulic Cylinders
Packing:	bundle with steel strip and PE sheet package or wooden case.
